Sic Firebrick Silicon Carbide Brick


   Item

Coke Oven Silica Brick

Glass Furnace Silica Brick

Hot Blast Stove Silica Brick

JJG-94

JBG-95

JBG-96

JRG-95

SiO %

94.5

≥95

≥96

95

Fe2O3 %

1.5

≤1.0

≤1.0

1.3

CaO %

2.5

2.2

2.2

2.2

Refractoriness °C

1790

1790

1790

1790

Refractoriness under load T1,°C

1650

1650

1660

1650

Apparent porosity %

22(24)

22(24)

22(24)

22(24)

Cold crushing strength Mpa

40(35)

35(30)

35(30)

35(30)

True Density g/cm3

2.33

2.32

2.33

2.34

Thermal Expansion %

1000°C

1.28(1.30)

1000°C

≤1.25

1000°C

≤1.25

1000°C

1.26


Product specifications

Silicon carbide brick used the high purity silicon carbide(SIC) and industrial silicon powder as the primary materials.Shaped by vibration,made by high sintering.

Features

1. Good thermal conductivity
2. Good high temperature strength
3. Wear resistant and erosion resistant
4. Good thermal shock resistance
5. Good corrosion resistance
6. Good oxidation resistance

Suitable For

1. Non-ferrous metal smelting industry,ceramic,enamel and cement rotary kiln mouth, as well as glass annealing furnace and various kind of high temperature furnace.

2. Blast furnace lining,the lining of aluminium electrolytic bath,glass tank,structural ceramics,sanitary ceramics,domestic ceramics,electrotechnical porcelain refractory material, sinter powder metal industry.

3. Industrial ceramics bearing plate burning,pushing board, sagger; muff plate of annealing furnace;lining and ignitor of CFBB; lining of garbage incinerators,heat treatment electric heating furnace,soaking pit furnace etc.

Packing & Delivery

Wooden pallets with plastic film or according to yours

1. Strong packing protects the goods from any possible damage during transit.
2. Solid packing and overall stuffing prevent the cases from vibration and jarring.
3. Necessary precaution is taken to protect goods from pilferage or rain.

Every possible precaution is taken to ensure our products in prime condition when reach customers around the world.
